Precision.. Reliability.. Economy..
| Part No. | Product Name | D | L | Size | Nut | Clamping range | MT No. | Kgs | Group |
|---|---|---|---|---|---|---|---|---|---|
| F1MTA3X-ERS32070 | MTA3 Tang type ER 32 070 | 50 | 70 | ER32 | F15500-32ERS | 2.0 – 20.0 | MT 3 | 0.8 | A |
| F1MTA3X-ERS40075 | MTA3 Tang type ER 40 075 | 63 | 75 | ER40 | F15500-40ERS | 3.0 – 26.0 | MT 3 | 1 | A |
| F1MTA4X-ERS32075 | MTA4 Tang type ER 32 075 | 50 | 75 | ER32 | F15500-32ERS | 2.0 – 20.0 | MT 4 | 1.1 | A |
| F1MTA4X-ERS40075 | MTA4 Tang type ER 40 075 | 63 | 75 | ER40 | F15500-40ERS | 3.0 – 26.0 | MT 4 | 1.3 | A |
| Part No. | Product Name | D | L | G | Size | Nut | Clamping range | MT No. | Kgs | Group |
|---|---|---|---|---|---|---|---|---|---|---|
| F1MTB3X-ERS32070 | MTB3 Threaded Type ER 32 070 | 50 | 70 | M12 | ER32 | F15500-32ERS | 2.0 – 20.0 | MT 3 | 0.7 | A |
| F1MTB3X-ERS40075 | MTB3 Threaded Type ER 40 075 | 63 | 75 | M12 | ER40 | F15500-40ERS | 3.0 – 26.0 | MT 3 | 0.9 | A |
| F1MTB4X-ERS32075 | MTB4 Threaded Type ER 32 075 | 50 | 75 | M16 | ER32 | F15500-32ERS | 2.0 – 20.0 | MT 4 | 1 | A |
| F1MTB4X-ERS40075 | MTB4 Threaded Type ER 40 075 | 63 | 75 | M16 | ER40 | F15500-40ERS | 3.0 – 26.0 | MT 4 | 1.3 | A |
